Product Brief

Unique design of open channel allow user to access of note moving passage and sensor areas to jammed note removal and cleaning without having to loosen one single screw even no technician’s support.

Easy updates and upgrades simply plug in USB flash drive or insert of SD card to SD slot, which saved new software in and switch on the machine. New currencies, Fake Note upgrades, any other languages or same updates and upgrades can also be sent by email. All in all that you no longer have to wait for a technician just only to wait for the email.

Specifications
  • Fully automatic currency recognition and mixed value counting function
  • Easy operations with color touch screen and heavy-duty durable keys
  • Various mood of counting – Mix, Sort, Face, Orientation, Image, PCS
  • UV, MG, IR, MT and CIS Detecting function
  • Double CIS sensor with RGB & IR light sources
  • Value discrimination with serial number recognition and reporting – printing**
  • Connect with PC and data transferring and software upgrading ability
  • UV+MG+MT+IR Image detecting system and high quality fake note recognition possibility
  • Automatically stop with alarm, when meets the counterfeit or abnormal banknote and shows the error cord on display
  • Currency available - EURO, USD, GBP, INR, CNY, SAR, UAD and up to 6 currencies optional
  • Half note, Chained / Double note detection
  • Automatic / Manual start function
  • Add function
  • Batch presetting function
  • Fully self-diagnosis function
  • Two counting speeds
  • Design of open channel, easy maintenance and jam removing
  • Compact design – compact in size and avant-garde design
  • Available ports RS-232, RJ-45 and USB, SD card slot upgrade software
  • Remote Customer display
  • Thermal Printer **(Optional)
Parameters
Counting Speed : 1,000 pcs/min - in SDC and MDC mode
1,200 pcs/min - in CNT mode
Materials of bills : Paper and Polymer Substrate
Banknote Size : 85 x 60 x 0.08 mm - 190 x 100 x 0.12 mm
Hopper capacity : 500 pcs
Stacker capacity : 200 pcs
Display : 3.5 Inch Color TFT LCD and full Graphic UI notification
Power supply : AC 100-240 V, 50-60 Hz
Power consumption : 50 w
Dimension : 280(W) x 260(L) x 270(H) mm
Net weight : 7 kg
